[post_content] =>
Line Drawing
Specifications
Power Source
Provided by NHX-80
Communication
Hands-free
Communication Output
100mW @ 20 ohms
Calling Capacity
Up to 80 stations
Wiring
3 twisted pair shielded low capacitance cable (12 pF/Ft) from NHX-80X Aiphone #862208
With NHR-3A-4 Zone Indicator Light: 3 twisted pair + 1 common wire per zone Aiphone #862208
Wiring Distance
165’ to farthest patient station
330’ Max. trunk line distance (per trunk), including length of trunk line, plus wire length t-tapped to each patient station from trunk line.
Mounting
Flush mount
Electrical Box
2-gang box or ring
Certification
UL 1069 Listed
C-UL Canadian Standard C22.2
Dimensions
4-1/2” x 4-9/16” x 1-13/16”
[post_title] => NH-1SA-A Technical Specifications
[post_excerpt] =>
[post_status] => publish
[comment_status] => open
[ping_status] => open
[post_password] =>
[post_name] => nh-1sa-a-spec-sheet
[to_ping] =>
[pinged] =>
[post_modified] => 2025-03-13 10:26:21
[post_modified_gmt] => 2025-03-13 17:26:21
[post_content_filtered] =>
[post_parent] => 0
[guid] => https://aiphone.local/kb/nh-1sa-a-spec-sheet/
[menu_order] => 0
[post_type] => kb
[post_mime_type] =>
[comment_count] => 0
[filter] => raw
)
[1] => WP_Post Object
(
[ID] => 37458
[post_author] => 18
[post_date] => 2021-11-30 16:07:26
[post_date_gmt] => 2021-12-01 00:07:26
[post_content] =>
Line Drawing
Specifications
Power Source
24V DC supplied by two PS-2420UL power supplies
Current Consumption
Maximum 4A
Station Capacity
50 Stations. For an additional 30 stations add NHR-30K.
Wire Type
All wire is twisted, shielded, low capacitance (12 pF/Ft).
5 twisted pair to NHX-50M Master Station - Aiphone wire
#862210
3 twisted pairs to NHR-SP Duty Station - Aiphone wire
#862208
3 twisted pairs (plus 1 wire for zone light) trunk line to patient stations - Aiphone wire
#862208
5 conductors to NHR-3A-4 Zone Light - Aiphone wire #841806
Wiring Distance
22AWG
65’ to NHX-50M
65’ to NHR-SP
165’ to the farthest patient station (ea. trunk)
330’ Max. wire distance per trunk line, including wire length t-tapped to each patient station from the trunk line.
18AWG
165’ to NHR-3A-4
Mounting
Surface wall mount or 3-gang box
Dimensions
18-1/8” H x 13-3/8” W x 3-7/8” D
Weight
Approx. 0.46 lbs (210g)
[post_title] => NHX-80X Technical Specifications
[post_excerpt] =>
[post_status] => publish
[comment_status] => open
[ping_status] => open
[post_password] =>
[post_name] => nhx-80x-technical-specifications
[to_ping] =>
[pinged] =>
[post_modified] => 2025-04-10 13:55:48
[post_modified_gmt] => 2025-04-10 20:55:48
[post_content_filtered] =>
[post_parent] => 0
[guid] => https://aiphone.local/kb/nhx-80x-technical-specifications/
[menu_order] => 0
[post_type] => kb
[post_mime_type] =>
[comment_count] => 0
[filter] => raw
)
[2] => WP_Post Object
(
[ID] => 37460
[post_author] => 18
[post_date] => 2021-12-01 16:24:31
[post_date_gmt] => 2021-12-02 00:24:31
[post_content] =>
Line Drawing
Specifications
Mounting
Mounts to back of NHX-80X
Station Capacity
Allows for an additional 30 stations to be integrated with the NHX-50M with the use of NHX-30G
Weight
Approx. 0.37 lbs (170g)
[post_title] => NHR-30K Technical Specifications
[post_excerpt] =>
[post_status] => publish
[comment_status] => open
[ping_status] => open
[post_password] =>
[post_name] => nhr-30k-technical-specifications
[to_ping] =>
[pinged] =>
[post_modified] => 2025-04-10 13:57:01
[post_modified_gmt] => 2025-04-10 20:57:01
[post_content_filtered] =>
[post_parent] => 0
[guid] => https://aiphone.local/kb/nhr-30k-technical-specifications/
[menu_order] => 0
[post_type] => kb
[post_mime_type] =>
[comment_count] => 0
[filter] => raw
)
[3] => WP_Post Object
(
[ID] => 37462
[post_author] => 18
[post_date] => 2021-12-01 16:57:29
[post_date_gmt] => 2021-12-02 00:57:29
[post_content] =>
Line Drawing
Specifications
Power Source
Supplied by Central Control Unit (NHX-80M)
Power Consumption
80mA Standby, 500mA Maximum
Communication
Handset or Push-to-talk
Capacity
50 Stations
Call Priority
- Cord-out trouble call
- Urgent bathroom call and NHR-3TS common area bathroom/staff call
- Routine call (sub station call-ins on standby connected according to urgency level and time of call)
Warning Tones
- Line-off trouble alert when the station is unplugged (buzzer activated at NHX-50M) – to silence, plug in CN1047 shorting connector inside NHX-80X and call for service
- 90 sec. elapse timer – call tone goes up to HIGH level
- 90 sec. off-hook timer – steady tone will notify handset is off-hook
Wiring
Master Station to Central Control Unit: 5 twisted pair, low cap, PE, overall shield — use Aiphone
#862210
Wiring Distance
Master Station to Central Control Unit: 65'(22 AWG)
Mounting
Desk-top use
Operating Temperature
32° ~ 104°F (0° ~ 40°C)
Dimensions
3-1/4” H x 11” W x 8-1/4” D
