Diagram

[mkb-info]Tenant stations shown are the GT-1A. The GT-1D tenant stations can also be used and wired in the same manner.[/mkb-info]

Wire Type

Audio Line 20AWG (0.8mm) 2 Conductor Solid Non-Shielded PE Insulated

Power

PS24 PS-2420UL PT Power Transformer (Contact electric strike or magnetic lock manufacturer for power requirements)

Wiring Distances

Max. wire distance from a distribution point to any tenant is 980’ (300m). Max. cumulative wire distance is 8200’ (2500m). Refer to the GT Series Installation Manual for complete wire distance information.   [mkb-tip]Distribution Point: (GTW-DP) Available in North America. This can be any device that parallels or commons the R1 / R2 connection. (Terminal strip, punch down block, wire nuts, etc.)[/mkb-tip]   [post_title] => Wiring: GT Standard System Audio Only [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => open [post_password] => [post_name] => wiring-gt-standard-system-audio-only [to_ping] => [pinged] => [post_modified] => 2025-03-13 10:26:23 [post_modified_gmt] => 2025-03-13 17:26:23 [post_content_filtered] => [post_parent] => 0 [guid] => https://aiphone.local/kb/wiring-gt-standard-system-audio-only/ [menu_order] => 0 [post_type] => kb [post_mime_type] => [comment_count] => 0 [filter] => raw ) ) [post_count] => 1 [current_post] => -1 [before_loop] => 1 [in_the_loop] => [post] => WP_Post Object ( [ID] => 37025 [post_author] => 18 [post_date] => 2021-08-14 18:20:56 [post_date_gmt] => 2021-08-15 01:20:56 [post_content] =>

Diagram

[mkb-info]Tenant stations shown are the GT-1A. The GT-1D tenant stations can also be used and wired in the same manner.[/mkb-info]

Wire Type

Audio Line 20AWG (0.8mm) 2 Conductor Solid Non-Shielded PE Insulated

Power

PS24 PS-2420UL PT Power Transformer (Contact electric strike or magnetic lock manufacturer for power requirements)

Wiring Distances

Max. wire distance from a distribution point to any tenant is 980’ (300m). Max. cumulative wire distance is 8200’ (2500m). Refer to the GT Series Installation Manual for complete wire distance information.   [mkb-tip]Distribution Point: (GTW-DP) Available in North America. This can be any device that parallels or commons the R1 / R2 connection. (Terminal strip, punch down block, wire nuts, etc.)[/mkb-tip]   [post_title] => Wiring: GT Standard System Audio Only [post_excerpt] => [post_status] => publish [comment_status] => open [ping_status] => open [post_password] => [post_name] => wiring-gt-standard-system-audio-only [to_ping] => [pinged] => [post_modified] => 2025-03-13 10:26:23 [post_modified_gmt] => 2025-03-13 17:26:23 [post_content_filtered] => [post_parent] => 0 [guid] => https://aiphone.local/kb/wiring-gt-standard-system-audio-only/ [menu_order] => 0 [post_type] => kb [post_mime_type] => [comment_count] => 0 [filter] => raw ) [comment_count] => 0 [current_comment] => -1 [found_posts] => 1 [max_num_pages] => 1 [max_num_comment_pages] => 0 [is_single] => [is_preview] => [is_page] => [is_archive] => 1 [is_date] => [is_year] => [is_month] => [is_day] => [is_time] => [is_author] => [is_category] => [is_tag] => [is_tax] => 1 [is_search] => [is_feed] => [is_comment_feed] => [is_trackback] => [is_home] => [is_privacy_policy] => [is_404] => [is_embed] => [is_paged] => [is_admin] => [is_attachment] => [is_singular] => [is_robots] => [is_favicon] => [is_posts_page] => [is_post_type_archive] => 1 [query_vars_hash:WP_Query:private] => dcf6eaa2ff3668f63ab720384c8dc8c1 [query_vars_changed:WP_Query:private] => 1 [thumbnails_cached] => [allow_query_attachment_by_filename:protected] => [stopwords:WP_Query:private] => [compat_fields:WP_Query:private] => Array ( [0] => query_vars_hash [1] => query_vars_changed ) [compat_methods:WP_Query:private] => Array ( [0] => init_query_flags [1] => parse_tax_query ) )
